TRAILER SPECIFICATIONS
| Trailer | Axle Weight (lbs) | Spring Weight (lbs) | Wheel Size |
| AWJ46 | 2000 | 2000 | 13″ |
| AVB46 | 2000 | 2000 | 13″ |
| AWJ50 | 3500 | 2500 | 13” |
| AWV50 | 3500 | 2500 | 13″ |
| AWJ56 | 3500 | 3500 | 14″ |
| AWB18 | 3500 | 2500 | 13″ |
| AWS16 | 3500 | 2500 | 13″ |
| AVB56 | 3500 | 3500 | 14″ |
| AW16 | 3500 | 2500 | 13″ |
| AW17 | 3500 | 2500 | 14″ |
| AW18 | 3500 | 3500 | 14″ |
| AW19 | 3500 | 3500 | 14″ |
| AW20 | 3500 | 3500 | 14″ |
| AW21 | 3500 | 3500 | 14″ |
| AW22 | 3500 | 3500 | 14″ |
| AW24* | 3500 | 3500 | 14″ |
| AWXB21* | 3500 | 3500 | 14″ |
| AWXB23* | 3500 | 3500 | 14″ |
| AWSK18 | 3500 | 2500 | 13″ |
| AWD16 | 3500 | 2500 | 13″ |
| AWD18 | 3500 | 2500 | 13″ |
| AWDB18 | 3500 | 2500 | 13″ |
| AWHD15 | 2000 | 2000 | 13″ |
| AWHD16 | 3500 | 2500 | 13″ |
| AWHD17 | 3500 | 3500 | 13″ |
| AWHD18 | 3500 | 3500 | 14″ |
| AWHD20 | 3500 | 3500 | 14″ |
| AWHD22 | 3500 | 3500 | 14″ |
* Tandem Axle with Brakes on One Axle
** All Trailers come standard with Bias Tires. Bias Tires are for occasional use only.
If you plan to tow long distances or very frequently, Xpress Boats recommends that you upgrade to Radial Tires or to Aluminum Wheels which include Radial Tires.
OPTIONS
Lighted Logo Trailer Step (Both Sides)
Aluminum Spare Tire and Mount
Aluminum Wheel Upgrade (Per Axle)
Brakes on Second Axle of Tandem
Single Axle w/ Brakes
Galvanized Spare Tire and Mount
Swing Away Tongue
Tandem Axle w/Brakes on One Axle
Tandem Axle w/Brakes on Both Axles
15” Aluminum Wheel Upg. From 14” Alum
18” Aluminum Spare Tire & Mount
All options may not be available on all trailer sizes.
PACKAGES
| Xtreme Trailer Package (Requires Tandem Axle Trailer) 18″ Aluminum Wheel Upgrade (2 Axles), Custom Tread Plate Tandem Fenders, HD Jack Stand, Flush Mounted Tail Lights and Backup Lights, Ratchet Buckles, and SeaDek Fender Pads. |
| 6″ Frame Xtreme Trailer Package (Req. Tandem/Brake w/ Alum Wheels) 18″ Aluminum Wheel Upgrade (2 Axles), Custom Tread Plate Tandem Fenders, HD Jack Stand, Flush Mounted Tail Lights and Backup Lights, Ratchet Buckles, and SeaDek Fender Pads. |
| Saltwater Trailer Package Composite Bunk Covers and Upgraded Bow Roller. |
High Performance Hubs
100,000 MILE LUBRICATION SYSTEM Lithium complex fortified with rust and oxidation inhibitors, high pressure additives provide a high degree of water resistance and washout properties.
- 100,000 mile or 6 year limited warranty* (no extra cost)
- “No Touch” lubrication system
- No need for periodic re-greasing or inspection
- Reusable dust cap is threaded for easy removal should the need occur.
TRAILER/BOAT PAIRING
| AWSK18 | SKIFF185 | |||||||
| AW16 | H16DB | |||||||
| AX17 | H17 | H17C | ||||||
| AW18 | H18 | H18C | ||||||
| AW19 | X19PRO | H190B | ||||||
| AW20 | H20 | H20C | H20B | |||||
| AW21 | X21PRO | H210B | ||||||
| AW22 | H22B | |||||||
| AW24 | H24B | |||||||
| AWXB21 | X21B | |||||||
| AWXB23 | X23B | X23B-L | ||||||
| AWB18 | BAYOU 18 BAYOU 18V | BAYOU 17 BAYOU 17V | ||||||
| AWD16 | XTS16 | |||||||
| AWDB18 | H18DB | |||||||
| AWHD15 | HD15DBX | HD15VJ | HD15DDP | |||||
| AWHD16 | HD16DBX | HD16DB | HD16VJ | HD16DDP | ||||
| AWHD17 | XP170 XP180 | XP18CC | HD17VJ HD18VJ | HD17DDP HD18DDP | ||||
| AWHD18 | XP185 CATFISH | |||||||
| AWHD20 | XP200 | XP20CC | XP200 CATFISH | HD20VJ | HD20DDP | SW20B | ||
| AWHD22 | SW22B |
6” Frame Extreme Trailer Package
Comes standard w/X21Pro, X-Bay & H24B only.
Single Axle Trailer
Comes standard w/Hyper-Lift Bass, Xplorer Bass, H22B, H210B, H20B, H190B, Shallow Water Bay, Xplorer CC, Skiff 185, Hyper-Lift Crappie, Xplorer Catfish, and all Hunting Series boats.
